standard Titanium powder sintered filter backwash water filter

FOB Reference Price:Get Latest Price
US $1-10 / Pieces | 10 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
TS Filter
Model Number:
TI filter
filter media:
stainles steel 316/304
outer diameter:
60mm/80mm
filter length:
10'',20'',30'',40''
micron:
0.45um-50um
efficiency:
>99.99%
Certificate:
FDA,2002/72/EC
featture:
high temperature and high pressure resistant
application:
suitable for extreme environment steam filtration
Supply Ability
Supply Ability:
500000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Export standard package: 1pc filter cartridge/ 1 polybag/ 1 small carton; 12 or 20 pcs in one big carton,or according to customer's requirement.
Port
Shanghai/Ningbo
Lead Time :
3-15 days

welcome to>>Hangzhou Tianshan Precision Filter Material Co., Ltd.



Comprehensive presentation

Specifications



High purity titanium powder (99%) sintered under high temperature . Resist to strong acid, alkaline and Ozone Oxidation.Can be washable and reusable . Suitable for solid / liquid / gas  separation and purification in  low -viscosity liquid material  (with rigid particles )



Feature







Resistant high temperature and pressure

Resistant strong acid and alkali

Good permeability and resist to ozone oxidation

It can be washed repeatedly,reusable .low cost in operation

Specification





Outer diameter:   Φ60-Φ63mm

Length:           10-40 inch

Porosity:         30%-50%

Operating parameters







PH:               1~4

Flow rate:       0.5T/h

Max.temperature: 200℃(Wet)

Max.differential:0.50Mpa

Typical Applications











Steam filtration

Steam filtration

Filtration stage after  Ozone sterilization and  filtration of

Ozone aeration

guard filtration in decarbonization  and Dilution of Transfusion,

small injection, oral

Highly corrosive liquid and gas purification

Liquid or gas in high temperature and pressure



ORDER INFORMATION



PRODUCTMICRONOuter Dia.ADAPTERLENGTH    O-RING / GASKET
TI100-1umD60-60mmNIL- Cut Ends (Cylinder)10-10" S-silicone;     N-nitrile
 300-3umD80-80mmAA- DOE ( With Gaskets)20-20" E-epdm ;       T-teflon (Encaptulated)
 500-5um BF-222/ Seal30-30" V-vition
 1000-10um CF-226/ Seal40-40"
 2000-20um YBP- 1" BSP Threaded05-5"
   HBP- 1/2" BSP ThreadedOther-XXHow to Order?- Example


Titanium Sintered; Micron:5um; Outer Dia.:60mm;

Length:10";Adapter:1"BSP; O-rings: Silicone

     Selection Code is: TI500D60YBP10S
