high flow PES filter cartridges for liquid crtitical filtration(0.01 micron)

FOB Reference Price:Get Latest Price
US $30-50 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
TS Filter
Model Number:
PES
Filter Media:
PES membrane filter cartridges
Micron:
0.04um/0.1um/0.2um/0.45um/0.65um
Length:
5''/10'' / 20'' / 30''/40''
Application 1:
Pharmaceuticals;APIs;Biologics
Application 2:
Fermentation Broths
Application 3:
Fine Chemicals
Application 4:
Food &Beverages,Wine,Beer,Mineral Water
Application 5:
Semi-Conductor,LCD Display;Dics
PH Value compatibility:
2-13
Material Safety:
Meet the current FDA and 2002/72/EC standard
Supply Ability
Supply Ability:
500000 Piece/Pieces per Year
Packaging & Delivery
Packaging Details
Export standard package: 1pc filter cartridge/ 1 polybag/ 1 small carton; 12 or 20 pcs in one big carton
Port
Shanghai
Lead Time :
3-15 days

welcome to>>Hangzhou Tianshan Precision Filter Material Co., Ltd.



Comprehensive presentation











-03




























Specifications






Specification



Features





Extremely high flow rate

No adhesives

High purity water flushing,no fiber shedding

Wide chemical compatibility

Low binding to protein,and microorganism

100% integrity test

Material of Construction







Filter Media: PES asymmetric membrane

Support layer/drainage layer:Polypropylene

Cage/Endcap:Polypropylene

Core:Polypropylene/Stainless steel

Dimension







Outer diameter:Φ68,Φ69mm

Inner diameter:Φ33mm

Filter area:5~40in

Core:0.65m2/10in

Operation Conditions









PH range:2~13

Normal working temperature:≤60℃

Max working temperature:85℃

Max pressure drop:0.42Mpa/25℃   0.10Mpa/80℃

Sterilization:Steam Sterilization for 30 minutes

at 121±2℃,autoclave 30 minutes optional

Extractables



Endotoxin:<0.25EU/ml

Extractables:<0.03g/ 10"

Typical water flow

rate (10")


Typical applications







Food&Beverage:wine,mineral water,pure water,juice

Electonics:ultrapure water,disk,display,multi silicon

Chemical: raw material clarification and sterilization

Pharma: API, LPV, blood serum, biological products, protein solution,bacteriophage



Ordering information:

GRADEPRODUCTMICRONADAPTERLENGTH                    O-RING / GASKET
H - ChemicalIPS004-0.04umAA- DOE10-10" S-silicone;      N-nitrile
E - ELECTRONIC  010-0.1umCN-226/FIN20-20" E-epdm ;        T-teflon (encaptulated)
P - Phamar 020-0.2umBN-222/FIN30-30" V-viton
F - Food 045-0.45umBF-222/ FLAT SEAL40-40"How to Order?- Example
  065-0.65umCF-226/FLAT SEAL05-5"

Pharmaceutical grade; Micron:0.45um;

Length:10"  ADAPTER: DOE; Gakset: Silicone.

Selection Code is: PIPS045AA10S

   EN-222 three locking  ears /Fin
