High efficiency Electronics Grade PES membrane cartridge filter for DI and high purity water in

FOB Reference Price:Get Latest Price
US $30-60 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
TS Filter
Model Number:
PES
Grade:
Pharmceutical grade
Filter Cage, Core::
PP
Filter Diameter::
69 mm
Material:
PES
Usage:
DI and High purity water filter cartridges
Filter Efficiency::
>99.99%
Certificate:
SGS ISO IFTS etc
Filter length::
5, 10, 20, 30, 40 inch
Filtration Area::
0.65m2(10'')
Type:
WNF-0.45-40US-M3
Supply Ability
Supply Ability:
20000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
1pc filter cartridge/ 1 polybag/ 1 small carton; 12 or 20 pcs in one big carton.
Port
Shanghai/Ningbo
Lead Time :
3-7 working day





High efficiency  Electronics Grade PES membrane cartridge filter  for DI and high purity water in

Product Description



These PES membrane filters are constructed of absolute rated, hydrophilic polyethersulfone (PES) membrane and polypropylene components.



Polyethersulfone (PES) is low protein binding and excellent resistant to hydrolysis, therefore a good choice for terminal filtration(bacterial removal) of water treatment, food&beverage, pharmaceutical applications, etc.



 _MG_0464012

Specifications



Features











Extremely high flow rate

No adhesives

High purity water flushing,no fiber shedding

Wide chemical compatibility

Low binding to protein,and microorganism

100% integrity test

Material of Construction







Filter Media: PES asymmetric membrane

Support layer/drainage layer:Polypropylene

Cage/Endcap:Polypropylene

Core:Polypropylene/Stainless steel

Dimension







Outer diameter:Φ68,Φ69mm

Inner diameter:Φ33mm

Filter area:5~40in

Core:0.65m2/10in

Operation Conditions









PH range:2~13

Normal working temperature:≤60℃

Max working temperature:85℃

Max pressure drop:0.42Mpa/25℃   0.10Mpa/80℃

Sterilization:Steam Sterilization for 30 minutes

at 121±2℃,autoclave 30 minutes optional

Extractables



Endotoxin:<0.25EU/ml

Extractables:<0.03g/ 10"

Typical water flow

rate (10")


Typical applications







Food&Beverage:wine,mineral water,pure water,juice

Electonics:ultrapure water,disk,display,multi silicon

Chemical: raw material clarification and sterilization

Pharma: API, LPV, blood serum, biological products, protein solution,

bacteriophage



Ordering information:

GRADEPRODUCTMICRONADAPTERLENGTH                    O-RING / GASKET
H - ChemicalIPS004-0.04umAA- DOE10-10" S-silicone;      N-nitrile
E - ELECTRONIC  010-0.1umCN-226/FIN20-20" E-epdm ;        T-teflon (encaptulated)
P - Phamar 020-0.2umBN-222/FIN30-30" V-viton
F - Food 045-0.45umBF-222/ FLAT SEAL40-40"How to Order?- Example
  065-0.65umCF-226/FLAT SEAL05-5"

Pharmaceutical grade; Micron:0.45um;

Length:10"  ADAPTER: DOE; Gakset: Silicone.

Selection Code is: PIPS045AA10S

   EN-222 three locking  ears /FinOther-XX
